The Magic of Bloom Filters ​

A deep dive into Bloom Filters in Go. We build one from scratch, optimize it with Kirsch-Mitzenmacher, and discover why your choice of hash functions might not matter as much as you think. Or... do they?

Bloom Filter Hero Image

The "Hmmm, Probably?" Data Structure ​

I recently needed a way to check if a key already existed in a dataset for a project. My first instinct was the classic move: cache it! Throw a Hash Map at it! But then I started thinking about scale. If you have millions of keys and you store every single one in a traditional cache, you're going to burn gigabytes of expensive RAM just to hold onto strings you might need to query. And what happens when someone queries a key that doesn't exist? Your cache misses, you hit the database, search the index, and then return a 404. Thousands of times a second.

This isn't a hypothetical problem. In distributed systems, this pattern is called cache penetration — where queries for non-existent data bypass the cache and hammer the database directly. It's such a well-known problem that AWS explicitly recommends Bloom filters as the mitigation in ElastiCache. Attackers don't need to find valid data — they just need to overwhelm your backend with misses. Your database I/O goes through the roof.

We need a way to answer the question "Does this key exist?" instantly, in memory, without storing massive strings or allocating gigabytes. This is exactly how Apache Cassandra skips SSTables without touching the disk, how Google Bigtable avoids disk lookups for non-existent rows, how Ethereum's logsBloom (pdf) lets clients scan block headers instead of full block bodies, and how Mozilla Firefox's CRLite compresses the entire internet's revoked certificates into a ~10 MB download.

Enter the Bloom Filter ​

A Bloom filter is a simple, space-efficient probabilistic data structure, originally described by Burton Howard Bloom in 1970. By "probabilistic", I mean it can't tell you exactly what is in a set, but it can answer the question "Is this item in the set?" with a very specific guarantee:

  • "No." (And it is absolutely, 100% right).
  • "Hmmm, Probably?" (It might be right, or it might be a false positive).

There are no false negatives in a Bloom filter. If the filter says a key doesn't exist, the key definitively doesn't exist. You just saved a disk read, a network hop, and/or a database query. For Cassandra, this means skipping entire SSTables without touching the disk. For Ethereum, it means scanning compact block headers instead of replaying every transaction.

What I thought would be a Saturday afternoon project turned into three days of staring at benchmark numbers and questioning everything I knew about hashing 😅. Let's dive in.

The VIP Bouncer ​

Think of a Bloom filter like a wildly efficient bouncer at an exclusive nightclub.

When you walk up to the door and give him your ID (the data), he doesn't check a giant master list of all 10,000 VIP members. Instead, he just has a single sheet of paper with thousands of tiny, numbered checkboxes (the bits).

He also has three completely different mathematical formulas in his head (the Hash Functions) that he applies to your name:

  1. Formula A says: your name maps to box #42.
  2. Formula B says: your name maps to box #105.
  3. Formula C says: your name maps to box #12.

If you are actually on the VIP list, the bouncer already checked all three of those exact boxes earlier in the day when the list was created.

When you show up, he looks at those three specific boxes on his sheet. If even one of them is empty, he knows for an absolute fact you aren't on the list. You are rejected instantly. (This is the definitive No).

But, if all three boxes are already checked, he lets you in. (This is the Probably).

Why "probably"? Well, the bouncer has been checking boxes for thousands of other people all night! Maybe Pedro caused him to check box #42, Miguel made him check #105, and Carlos caused #12 (yes, this is a latino bar). The boxes are checked, but not because of you. You just snuck in based on the overlapping checkmarks of three completely different people. That is a false positive.

By making the sheet of paper bigger (more bits) or giving him more formulas to calculate (more hashes), we can mathematically control exactly how often someone accidentally sneaks in.

Building the Filter ​

Let's build this in Go.

First, we need the "sheet of checkboxes" — a bit array. The more items we plan to store, the bigger the array needs to be (we'll work out the exact math in a moment). So how do we represent a potentially massive bit array in Go?

The simplest approach would be a boolean slice []bool, but that wastes an entire byte (8 bits) for a single True/False value — eight times more memory than necessary (ouch 😩). A []byte slice would be more efficient, but for best performance on modern 64-bit architectures, we want to align our memory directly with the CPU word size. Fetching a 64-bit word from memory and masking a single bit is something modern CPUs can do almost instantaneously.

We will use a slice of atomic.Uint64. Using atomics gives us concurrent safety for free — multiple goroutines can Add and Contains simultaneously without a mutex. This is important because in a real service, you'll have hundreds of goroutines hitting the filter concurrently.

We also need to hold onto the size of our bitset (m), the number of hash functions we use (k), and the actual hashing function we want to invoke.

go
// Filter represents a Bloom filter.
// We use atomic.Uint64 so that Add and Contains are fully concurrent-safe
// without requiring an external mutex. On modern 64-bit architectures,
// atomic operations on aligned 64-bit words are essentially free.
type Filter struct {
	bitset []atomic.Uint64
	m      uint64 // Total number of bits in the filter
	k      uint64 // Number of hash functions to apply per element
	hasher HashFunc
}

I love the functional option pattern in Go. It allows us to keep our APIs incredibly clean while remaining open for extension.

go
// HashFunc is a function that returns a new hash.Hash64.
// By defining an interface for our hasher, we avoid hardcoding a
// specific algorithm. This gives users the flexibility to swap
// the default hasher (FNV-1a) with a faster one (like Murmur3 or xxHash)
// if their use case requires maximum throughput.
type HashFunc func() hash.Hash64

Let's create an Option type and a specific WithHashFunc modifier so users can swap out the hash function if they want to.

go
// Option configures the Filter using the functional options pattern.
// This pattern allows us to provide sensible defaults while
// remaining open for extension later, without breaking the API.
type Option func(*Filter)

// WithHashFunc allows providing a custom hash function constructor.
func WithHashFunc(h HashFunc) Option {
	return func(f *Filter) {
		f.hasher = h
	}
}

Notice that we use hash.Hash64 from the standard library. By programming against an interface rather than a concrete struct, we leave the door open for consumers to inject high-performance hashers like Murmur3 or xxHash later. (Keep this in mind, because it completely bites us in the benchmarks later on 🤔).

Creating the Filter ​

We don't want to enforce arbitrary sizes or force users to guess how many bits they need. We want users to approach us with real-world constraints: "I have 10,000 items, and I only want a 1% chance of a false positive."

The math for this is well-known. We can calculate the optimal number of bits (m) and the optimal number of hash functions (k) using natural logarithms. The formulas come directly from Bloom's original 1970 paper, and the derivations are covered thoroughly in Mitzenmacher & Upfal's Probability and Computing (pdf) textbook.

go
// optimalM calculates the ideal total number of bits (m) needed to store
// `n` elements while maintaining a target false positive rate `p`.
// The formula is: m = - (n * ln(p)) / (ln(2)^2)
func optimalM(n int, p float64) uint64 {
	return uint64(math.Ceil(-1 * float64(n) * math.Log(p) / math.Pow(math.Log(2), 2)))
}

// optimalK calculates the ideal number of hash functions (k) to use
// for a given number of bits (`m`) and expected elements (`n`).
// The formula is: k = (m / n) * ln(2)
func optimalK(m uint64, n int) uint64 {
	return uint64(math.Ceil((float64(m) / float64(n)) * math.Log(2)))
}

Why do we need this balance? If your bit array (m) is too small, you'll end up checking every single box on the sheet of paper. Once every box is checked, the filter is useless — every query returns True (100% false positive rate). And if you use too many hash functions (k), you set too many bits per item, filling up your array even faster (it's a lose-lose 😩).

Armed with that math, our constructors look incredibly clean.

go
// NewFilter creates a Bloom filter directly with a specific bit size (m)
// and number of hash iterations (k).
func NewFilter(m int, k int, opts ...Option) *Filter {
	// Since each uint64 holds 64 bits, we divide `m` by 64.
	// We add 63 before dividing to ensure we round up.
	bits := uint64(m)
	size := (bits + 63) / 64
	f := &Filter{
		bitset: make([]atomic.Uint64, size),
		m:      bits,
		k:      uint64(k),
		hasher: fnv.New64a, // FNV-1a is in the standard library and computationally cheap.
	}

	for _, opt := range opts {
		opt(f)
	}

	return f
}

// NewFilterFromProbability creates a Bloom filter tailored for an expected
// number of elements (`n`) and a desired false-positive probability (`p`).
// Example: NewFilterFromProbability(10000, 0.01) creates a filter for 10k items
// with a 1% chance of a false positive.
func NewFilterFromProbability(n int, p float64, opts ...Option) *Filter {
	m := optimalM(n, p)
	k := optimalK(m, n)
	return NewFilter(int(m), int(k), opts...)
}

Notice in NewFilter how we align the requested bits into our []uint64 layer. Because len(bitset) operates on 64-bit words, we divide m by 64. We intentionally add 63 before dividing to ensure integer arithmetic rounds up, guaranteeing we never allocate slightly less space than we need!

The Kirsch-Mitzenmacher Optimization ​

A Bloom filter requires k independent hash functions. If our math says k should be 7, do we literally import 7 different hashing algorithms into our codebase? No, that's expensive and impractical (and honestly kind of ridiculous 😅).

The standard solution is the Kirsch-Mitzenmacher optimization (pdf), published in 2006. It proves mathematically that you only need two hash functions to simulate any number of independent hashes. Here's how it works:

You hash the data once using a strong 64-bit hasher. You then split that 64-bit result cleanly down the middle into two 32-bit halves (let's call them h1 and h2). You can then simulate an infinite number of totally independent hashes using a simple formula: hash_i = h1 + i * h2. That's it. No extra imports, no expensive re-hashing.

Now, where this gets experiential — when I first implemented the filter, I tried a naive approach: take the []byte data, append the loop counter (i) as a "seed", and hash it k times. I thought this would simulate independent hashes well enough. It did not. My validation tests expected a 1% false positive rate, and I got 9.8%. Why? Because appending a single sequential byte and re-hashing produces highly correlated bit patterns — the hashes clump together on the same bits, defeating the entire mathematical purpose of the filter.

When I applied Kirsch-Mitzenmacher, the false positive rate dropped from 9.8% straight down to ~1.1%. And because we only call .Write() and .Sum64() once instead of k times, the performance skyrocketed. You can see this applied directly in the Add and Contains methods below.

So we need one good 64-bit hash. Which one? If you look at the xxHash benchmarks, the throughput hierarchy is pretty clear: XXH3 tops everything at 31.5 GB/s, XXH64 follows at 19.4 GB/s, Murmur3 at 3.9 GB/s, and FNV64 trails at 1.2 GB/s. And it's not just speed — the xxHash benchmark suite scores hash quality on a 1-10 scale. XXH3, XXH64, and Murmur3 all score a perfect 10, while FNV64 gets a 5 with the note "poor avalanche properties". All three challengers have Go implementations with hand-tuned assembly for amd64 (zeebo/xxh3, cespare/xxhash, and twmb/murmur3), so on paper, the choice should be obvious.

But I defaulted to hash/fnv from Go's standard library anyway 😅. Zero dependencies, ships with every Go installation, and for a Bloom filter — where you're hashing tiny 16-byte keys, not streaming gigabytes — the raw throughput gap shrinks considerably. We'll put all four head-to-head in the benchmarks later and see if that "poor quality" score actually matters in practice.

Adding and Checking Data ​

With Kirsch-Mitzenmacher cleanly handled, the actual Add and Contains logic becomes elementary bitwise math.

When we Add, we allocate a fresh hasher, hash the data once, split the 64-bit result into two 32-bit halves right there, and then iterate k times. On each loop, we simulate the next hash via h1 + i*h2, modulo it into our m boundary, and flip the bit. We use atomic.Uint64.Or() to set bits and atomic.Uint64.Load() to read them, making the entire filter safe for concurrent use without a mutex.

go
// Add inserts data into the Bloom filter.
// It hashes the data once, splits the 64-bit result into two 32-bit halves,
// and simulates `k` independent hashes via Kirsch-Mitzenmacher.
// This method is safe for concurrent use.
func (f *Filter) Add(data []byte) {
	h := f.hasher()
	h.Write(data)
	sum := h.Sum64()

	// Split the 64-bit hash into two 32-bit halves for Kirsch-Mitzenmacher
	h1 := sum & 0xffffffff
	h2 := sum >> 32

	for i := range f.k {
		// Simulate k independent hashes: hash_i = h1 + i * h2
		bitIdx := (h1 + i*h2) % f.m

		// Atomically OR the bit to 1, safe for concurrent writes
		f.bitset[bitIdx/64].Or(1 << (bitIdx % 64))
	}
}

We divide the bit index by 64 to find the right word, modulo by 64 to find the bit within that word, and atomically OR (|) it to 1 without touching its neighbors. Clean, compact, and lock-free.

Notice something important here: we only ever flip bits to 1, never back to 0. That means once a bit is set, it stays set forever. If you're already thinking "wait, does that mean you can't delete items?" — yes, exactly. Multiple items can share the same bit positions, so unsetting a bit to remove one item could corrupt the membership of another. We'll come back to how real systems deal with this constraint shortly.

Checking if data exists (Contains) is the exact same logic in reverse.

go
// Contains checks if data might be in the set.
// If *any* of the `k` hash positions are 0, the element was definitively never added.
// If *all* of the positions are 1, it *might* have been added (or we have a collision).
// This method is safe for concurrent use.
func (f *Filter) Contains(data []byte) bool {
	h := f.hasher()
	h.Write(data)
	sum := h.Sum64()

	// Split the 64-bit hash into two 32-bit halves for Kirsch-Mitzenmacher
	h1 := sum & 0xffffffff
	h2 := sum >> 32

	for i := range f.k {
		bitIdx := (h1 + i*h2) % f.m

		// Atomically load the word and check the specific bit
		if (f.bitset[bitIdx/64].Load() & (1 << (bitIdx % 64))) == 0 {
			return false // Definitively not in the set
		}
	}
	return true // Probably in the set
}

Instead of setting the bit, we atomically load the word and use Bitwise AND (&) to isolate the bit. If the result is 0, that bit was never set — we short-circuit and return false instantly!

Putting It Through Its Paces ​

Ok, we have code. Now let's throw some numbers at it. All benchmarks use 16-byte keys (the size of a UUID — the most common key format you'll see in practice) and a sliding-window over a single random buffer to keep allocation noise out of the measurements. Ryzen 7 5800X, 16 threads, go test -bench=. -benchmem -benchtime=3s. Let's go.

Insert 1M Keys ​

First question: how long does it take to create a filter for 1 million items at 1% FPR and shove all of them in?

text
BenchmarkFilter_Insert1M-16    72    48876610 ns/op    9585059 bits    1198136 bytes/filter    7 hash_fns

~48.9 ms to insert 1 million UUID-sized keys — that's roughly 48.9 nanoseconds per key. The filter itself occupies 1.14 MB of memory (1198136 bytes / 1024² ≈ 1.14 MB), which matches the theoretical formula perfectly: m ≈ 9.58 million bits. For comparison, storing 1 million 16-byte keys in a Hash Map would cost you at minimum ~16 MB of raw key data, plus the map overhead (bucket pointers, hash tables) which balloons it to ~50-80 MB depending on load factor. The Bloom filter is 40-70× smaller.

Lookup Speed at Scale ​

Now the question that actually matters in production — with 1M items already packed in, how fast are lookups?

text
BenchmarkFilter_Contains1M-16    76990525    45.81 ns/op    8 B/op    1 allocs/op

45.81 nanoseconds per lookup. That's roughly 22 million lookups per second on a single core. Not bad for a data structure that fits in 1.14 MB 😲. The sole 8-byte allocation per call is the FNV hasher interface (we'll come back to this in a minute).

Concurrent Stress Test ​

Here's where the atomic.Uint64 design pays off. I spun up GOMAXPROCS goroutines (16 on my machine) doing a 50/50 mix of Add and Contains on a shared filter with 500K items already in it:

text
BenchmarkFilter_ConcurrentAddContains-16    459578769    7.401 ns/op    8 B/op    1 allocs/op

7.4 ns/op under full contention across 16 goroutines. That's over 135 million concurrent operations per second. No mutexes, no lock contention, no degradation. The atomic.Uint64 bet paid off big time. This is exactly the behavior you want when hundreds of goroutines are hammering the filter in production.

Does the Math Actually Hold Up? ​

All these benchmarks are great, but the whole point of the filter is the false positive rate. Does our 1% target actually work at scale? And here's the fun question — does the quality of the hash function matter? I inserted 1M UUID-sized keys, then queried 1M keys that were never inserted, using all four hash functions on the exact same data:

text
Filter size (m): 9585059 bits (1.14 MB)
Hash functions (k): 7

=== FPR Validation [FNV] (1M items) ===
  False positives: 9893
  Target FPR: 1.0000%
  Actual FPR: 0.9893%

=== FPR Validation [xxHash] (1M items) ===
  False positives: 10003
  Target FPR: 1.0000%
  Actual FPR: 1.0003%

=== FPR Validation [Murmur3] (1M items) ===
  False positives: 9924
  Target FPR: 1.0000%
  Actual FPR: 0.9924%

=== FPR Validation [XXH3] (1M items) ===
  False positives: 10038
  Target FPR: 1.0000%
  Actual FPR: 1.0038%

All four land within ~0.02% of the 1% target. That's basically noise. So the hash "quality" argument? FNV scores 5/10 on the xxHash benchmark suite with the note "poor avalanche properties", while xxHash, Murmur3, and XXH3 all score a perfect 10 — and yet they all produce identical false positive rates. With Kirsch-Mitzenmacher splitting a 64-bit hash into two 32-bit halves, even FNV's simpler distribution is plenty. The math works 🎉.

The Interface Allocation Plot Twist ​

Ok so if hash quality doesn't matter... which one is fastest? I ran FNV, xxHash, Murmur3, and XXH3 head-to-head on the same 16-byte UUID keys:

text
BenchmarkFilter_Add_FNV-16             	 88184716	    39.07 ns/op	     8 B/op	  1 allocs/op
BenchmarkFilter_Add_xxHash-16          	 66102469	    45.68 ns/op	    80 B/op	  1 allocs/op
BenchmarkFilter_Add_Murmur3-16         	 68050894	    52.44 ns/op	    96 B/op	  1 allocs/op
BenchmarkFilter_Add_XXH3-16            	 21895994	   153.5  ns/op	  1280 B/op	  1 allocs/op

FNV wins by a landslide. And XXH3 — the fastest hash in the world by streaming benchmarks — is dead last at nearly 4× slower than FNV. What happened?!

The -benchmem column tells the whole story. Look at B/op: FNV allocates 8 bytes per operation. xxHash? 80 bytes. Murmur3? 96 bytes. XXH3? A whopping 1280 bytes. They all show 1 allocs/op, but the size of each allocation is wildly different.

The Interface Allocation Penalty: Remember our HashFunc type (HashFunc func() hash.Hash64)? It returns a standard library interface. Because it returns an interface rather than a concrete struct, the Go compiler can't prove where the struct memory lives or how large it will be. This means a heap allocation every single time we call f.hasher() inside Add or Contains. FNV creates a tiny 8-byte struct. xxHash and Murmur3 create heavier wrappers. And XXH3? Its internal state for the SIMD-optimized algorithm needs 1280 bytes just to exist — a massive struct that gets allocated and thrown away on every. single. call. The very thing that makes XXH3 blazing fast on large data (wide internal SIMD state) makes it catastrophically expensive to construct for small keys. (So the "flexibility" of our interface design is literally costing us performance... ironic, right? 😅)

The Contains benchmarks tell the same story:

text
BenchmarkFilter_Contains_FNV-16        	160837656	    22.20 ns/op	     8 B/op	  1 allocs/op
BenchmarkFilter_Contains_xxHash-16     	123866376	    28.99 ns/op	    80 B/op	  1 allocs/op
BenchmarkFilter_Contains_Murmur3-16    	 91996884	    38.76 ns/op	    96 B/op	  1 allocs/op
BenchmarkFilter_Contains_XXH3-16       	 25076642	   145.9  ns/op	  1280 B/op	  1 allocs/op

For our use case — UUID-length keys with Kirsch-Mitzenmacher — FNV gives us the best speed, the smallest allocations, and (as we saw above) identical false positive rates. The streaming benchmarks on xxhash.com are measuring a completely different workload. When you're hashing 16 bytes at a time, the cost of creating the hasher dominates the cost of running it.

Living With the No-Delete Constraint ​

We already saw why deletion is off the table — bits are shared across items, so flipping them back to 0 would introduce false negatives. But this constraint also comes with a hidden upside: a Bloom filter stores no actual data, just bits. You can't reverse-engineer a bit array back into usernames. Even if an attacker gets a full memory dump, all they have is a bunch of 1s and 0s with no way to reconstruct the original data. And remember that cache penetration attack from the intro? With a Bloom filter in front, those millions of fake usernames get rejected instantly in memory. For an attacker to even reach your database, they'd need to guess a username that produces a false positive — and that only happens 1% of the time.

So what do you do when your data changes? A few strategies, each with real implementations you can study:

  1. Rebuild from scratch. If your dataset is relatively static, just rebuild the filter periodically. This is exactly what Apache Cassandra does during compaction — when SSTables are merged, the Bloom filters are rebuilt from the new data. For 1 billion items at a 1% false positive rate, the math gives us m ≈ 9.58 billion bits — that's roughly 1.12 GB. Sounds like a lot, but rebuilding a 1 GB bitset from a database dump is way cheaper than you'd think. And compared to storing those billion strings in a Hash Map? You'd need tens of gigabytes depending on average key length. The Bloom filter is an order of magnitude smaller.

  2. Counting Bloom Filters. Instead of storing a single bit per slot, store a small counter (usually 4 bits). When you add an item, increment the counters. When you delete, decrement. This was formalized by Fan, Cao, Almeida & Broder (2000) and there are production-ready Go implementations like tylertreat/BoomFilters. The tradeoff? Your filter is now 4× the memory — so that 1 billion item filter jumps from ~1.12 GB to ~4.5 GB. Still way smaller than a full string cache, but it's a real cost. (Nothing is free, right? 😅)

  3. Time-based rotation. Run two filters: a "current" and a "previous" generation. All new writes go to "current". Queries check both. Periodically, toss the old one and promote "current" to "previous". This is Akamai's "one-hit-wonder" filter (pdf) in action — a CDN Bloom filter tracks which URLs have been requested at least once, and only on the second request does the CDN actually write to disk cache. Since ~75% of web objects are requested exactly once, this avoids polluting the cache with ephemeral junk. Apache Nutch uses a similar rotation for web crawl deduplication — you don't care about URLs you saw 3 days ago, you just don't want to re-crawl the same page twice in the same pass.

Recapitulation ​

The standard library FNV hasher, a clean uint64 bitset, and Kirsch-Mitzenmacher. That's it. 1M UUID keys inserted in ~49ms. Lookups in under 46ns. ~118 million concurrent adds/second and ~135 million mixed ops/second across 16 goroutines. All in 1.14 MB of memory. And all three hash functions we tested — FNV, xxHash, Murmur3 — hit within 0.02% of the target FPR. Hash quality is a non-factor.

A simple, standard library hash function, allocated once, mapped cleanly across a uint64 slice, evaluates millions of items in fractions of a millisecond. Sometimes simple wins.

Fun footnote: our 1.14 MB filter fits comfortably in L3 cache, and that's partly why these numbers look so good — each lookup is just a few random bit checks against cached memory. What happens when a filter doesn't fit? Cloudflare found out when they pushed a 128 MB filter with 8 hash functions against billions of lines and each probe turned into a full RAM fetch. But that's Cloudflare-scale territory — most practical filters (even our 1-billion-item projection at 1.12 GB) will either fit in cache or sit behind an I/O boundary where the filter's memory footprint is still orders of magnitude cheaper than the alternative. For the vast majority of use cases, Bloom filters just work.

The next time you're sketching an architecture and instinctively reach for a caching layer to fix database load, ask yourself: Do I need to cache the data itself, or do I just need to know if the data exists?

Sometimes, all you need is a "Hmmm, Probably?".

Arrivederci! 👋

Further Reading ​

View source on GitHub
